CURT 31082 2-Inch Front Receiver Hitch, Fits Select Honda Ridgeline
A CURT front trailer hitch allows you to use the front end of your vehicle for a variety of towing applications. They can be used for mounting a winch, a snow plow, a number of towing accessories and can even be used for some trailering applications. When space is limited, a front trailer hitch is commonly used to hold a cargo carrier, freeing up space inside the vehicle for extra cargo and making the rear mount receiver available to pull a trailer. At the boat ramp, your boat trailer can be hitched up to the front receiver hitch, giving you better control over the trailer as you launch. Some of the other accessories that can be used with a front tow hitch are the CURT winch mount, step pad, license plate holder, spare tire mount, skid shield and tow hooks. All CURT front trailer hitches provide a useful receiver tube to accept a 2" x 2" shank, and they are commonly used on trucks, vans and SUVs. This front trailer hitch is rated for 5,000 lbs. GTW and 500 lbs. TW. It also has a straight-line pull rating of 9,000 lbs. It is designed to be a custom trailer hitch for certain years of the Honda Ridgeline (to verify your vehicle compatibility, see application info). It comes with all necessary hardware for a complete installation and is backed by a limited lifetime warranty.
  • Co-cured in a rust-resistant liquid A-coat, inside and out
  • Protected by a durable black powder coat finish
  • Rated to 5,000 lbs. gross trailer weight and 500 lbs. tongue weight
  • Compatible with a tow hook or shackle mount (9,000 lbs. straight-line pull)
  • Made with a vehicle-specific design for a custom fit
  • Provides a convenient attachment point for front mount accessories
  • Ideal for attaching a snow plow, cargo carrier or other front hitch accessories
  • Allows for easy maneuvering of a trailer into a tight spot
  • Tested for safety in accordance with SAE J684
  • Precisely welded for superior strength and fit

Information:

Precisely welded for superior strength and fit

Application Summary:

Year Make/Model
2017-2020 Honda Ridgeline
Attributes
ASIN B01MYFS5YV
Attachment Location Front
Box Height in Inches - XA 19, 19
Box Length in Inches - XA 41, 41
Box Width in Inches - XA 9, 9
California Proposition 65 Yes
Class ID 5, 5
Color Black, Black
Container Volume Cubic Feet - XA 0.00000, 0.00000
Container Volume Cubic Meter - XA 0.00000, 0.00000
Country of Origin (Primary) US
Drilling Required No, No
Finish Carbide Black Powder Coat, GLOSS BLACK POWDER COAT
Finish - XA GLOSS BLACK POWDER COAT, GLOSS BLACK POWDER COAT
Gross Trailer Weight 5000 lbs.
Gross Trailer Weight (lbs.) 5000
Harmonized Tariff Code (Schedule B) 8708998180
Hazardous Material Code N
Hitch Class III
Install Time 30 Minutes
Item Class - XA MFH, MFH
Item Height - XA 3.940, 3.940
Item Length - XA 31.440, 31.440
Item Width - XA 17.610, 17.610
Life Cycle Status Code Available to Order
Main Body Shape Square, Square
Master Case Height Inches - XA 0.000, 0.000
Master Case Length Inches - XA 0.000, 0.000
Master Case Volume Cubic Feet - XA 0.00000, 0.00000
Master Case Weight Lbs - XA 0.000, 0.000
Master Case Width Inches - XA 0.000, 0.000
Material Carbon Steel
Material - XA Carbon Steel, Carbon Steel
Mount Type Description - XA Blank, Blank
Mounting Hardware Included Yes
NAFTA Preference Criterion Code B
Pallet Qty - XA 24.000, 24.000
Pallet Total Height Inches - XA 0.000, 0.000
Pallet Total Weight Per - XA 0.000, 0.000
Parcel Allowed - XA Yes, Yes
Position Front
Price Code - XA 51, 51
Product Weight - XA 28.000, 28.000
Rate Class - XA 70.0, 92.5
Receiver Included Yes
Receiver Size 2
Receiver Tube Size 2 IN, 2 IN
Retail Height - XA 10.000, 31.000
Retail Length - XA 42.000, 4.000
Retail Width - XA 21.000, 18.000
Sales Family Code - XA HITCH, HITCH
Sales Family Description - XA HITCH, HITCH
Sales Group Description - XA FRONT MOUNT, FRONT MOUNT
SDR Required Flag N
Shipping Weight - XA 32.000, 28.000
Side Application Type Description - XA Blank, Blank
Straight Line Pull Capacity 9,000 LB, 9,000 LB
Tariff 301 - XA No, No
Tongue Weight (TW) 500 LB, 500 LB
Tongue Weight(TW) 500 LB
Truckload Volume Cubic Feet - XA 0.00000, 0.00000
Visibility Exposed
Warranty Limited Lifetime Warranty (One-Year Finish, One-Year Parts), Limited Lifetime Warranty (One-Year Finish, One-Year Parts)
WC Tongue Weight 500
Weight Carrying Capacity 5000
Weight Carrying Capacity (WC) 5,000 LB, 5,000 LB
Weight Carrying Capacity(WC) 5,000 LB
Weight Distribution (WD) N/A
Weight Distribution Tongue Weight (WDTW) N/A
Weight Distribution Tongue Weight(WDTW) N/A
Weight Distribution(WD) N/A
GTIN 00612314039968
